InterCom Systems
INTERCOM SYSTEMS (BUILDING INTERCOM SYSTEMS):
Building Security INTERCOMS are available in the range from 16 lines up to 4080 lines . SKYLINK intercom system comes with a lot of in built features and optional additional features can be added to the system such as Main Door Release, Cable Tamper Alert, Door Sensor, Vendor Alarm, Gas Leak Detector, Paging Port Facility, Panic Alert Button etc.
Models Of Intercom System
|
|
|
|
|
|---|---|---|---|---|
| Model | SL - ALFA - 64 Ports
(Wall Mountable) |
SL - ALFA - 128 Ports
(Wall Mountable) |
SL - Goldline | SL- Online |
| Capacity | 64 | 128 | 128 | 255 |
| Input Power | 170 to 270 VAC 50 Hz ± IO% | 170 to 270 VAC 50 Hz ± IO% | 170 to 270 VAC 50 Hz ± IO% | 170 to 270 VAC 50 Hz ± IO% |
| Line Voltage | 24 VDC | 24 VDC | 48 VDC | 48 VDC |
| Line Current | 35 to 40 m AMP | 35 to 40 m AMP | 35 to 40 m AMP | 35 to 40 m AMP |
| Cabling | Single Pair 0.5l mm dia | Single Pair 0.5l mm dia | Single Pair 0.5l mm dia | Single Pair 0.5l mm dia |
| Telephone | DTMF / DECADIC | DTMF / DECADIC | DTMF / DECADIC | DTMF / DECADIC |
| Amblent Condition | O-45ºC, 95% RH | O-45ºC, 95% RH | O-45ºC, 95% RH | O-45ºC, 95% RH |
| Weight | 7 kg | 14.5 kg | 14.5 kg | 24 kg |
| Dimension in cms (HxWXD) |
41x30x8 cm | 21x45x40 cm | 21x45x40 cm | 42x45x40 cm |
Features Of Intercom System:
Flat Owner can communicate with any other flat owner by just dialing the respective thet number (extension number)
Unlimited extensions can be on conference at a time.
Each extension can obtain the last 10 called numbers through the display unit installed at the security procedure to get callers identification.
This Feature keeps watch on Watchman, whether he is sleeping during night. Watchman's extension will ring at the predefined hours, (you can set 6 different alarm hours) System stores whether the watchman has lifted the telephone or not. The details of each watchan's result can be obtained through display by punching the code. Maximum of 4 extensions you can define as watchman.
If the dialed extension is busy (in conversation with other extension) you casn barge in between the conversation of that extension (This feature is useful in case of any important message to be passed to that extension )
The timing displayed at the security can be changed from the Master extension.
From any extension Dial "#49". You will directly get into the paging announcing part. If the paging port is busy you will get busy tone.
- If your flat is fitted with a door senser, it will ring alarm when any unauthorized entry takes place.
- Door senser consists of lock and key fitted next to your door.
- Lock and key is used to activate and desctive the door sensor.
Any standard telephone instrument having CLIP(DTMF type) equipment can be connected to the extension. This will diaplay the extension number from where you are getting the call. This is a restricted facility, for this facility to be allowed to any extension you have to programme the system from the master extension.
Each extension can have thier own morning alarm.
System strokes ladt 10 called number of each extension as well as last registered incoming call (missed call). Any extension giving more than eight rings to other extension becomes a registered incoming caller.
This Feature helps to restrict the strangers/blank calls to the flat. Any extensions like LIFT, TERRACE can be defined as NO MAN's extension so thet from such extension you will only be able to contact security not the flat.
In case of emergency lift the handset & Dial "#0" immediately display will show your flat number with siron.
System allow you to select one extension number (Hot line number) Which is automatically dialed after a delay of three seconds from lifing the handset.
- There is a seprate Panic Alert Button fitted next to your instrument.
- In case of emergency, Press the button.
- Alarm Bell will ring at the security with flat No. On the diaply board.
For activating this feature enabled extension should be terminated by the resistor provided along with system.
Any Messasge can be stored in the system, which will be announced to every extension as soon as the extension goes off hook.
This facility informs you the arrival/availability of the vender.
Procedure to get callers identification trough voice.
